Steiner DBAL-A3 Civilian Dual Beam Aiming Laser - Black

(No reviews yet) Write a Review
SKU:
9008
UPC:
000381890085
MPN:
9008
Availability:
In Stock If You Can Add To Cart!
Shipping:
Calculated at Checkout
MSRP: $1,864.49
$1,724.99
— You save $139.50
Frequently bought together:

Description

Steiner DBAL-A3 Civilian Dual Beam Aiming Laser - Black

Bring authentic military night-fighting capability to your tactical carbine with the Steiner DBAL-A3 Green Laser & IR Illuminator (Item #9008). Modeled directly after the standard-issue unit deployed by U.S. warfighters, this unrestricted commercial model is the first compact laser aiming device to integrate an eye-safe Class 1 infrared laser pointer, an adjustable IR illuminator, and a high-visibility green laser in a single rugged housing. Whether conducting close-quarters maneuvers or engaging targets at extended ranges in zero-light conditions, the DBAL-A3 delivers decisive aiming precision and seamless transitions between visible and night-vision operations.

Engineered for relentless reliability in the harshest environments, the DBAL-A3 features a direct-diode 520nm green laser capable of operating in extreme cold down to -20°C, alongside innovative defocused IR illumination technology that adjusts smoothly from wide CQB flood to tight mid-range beams. Housed in submersible, MIL-SPEC Type III hardcoat anodized 6061-T6 aircraft aluminum and equipped with dual remote cable ports featuring Visible Override, this unit mounts rapidly to any Picatinny rail via Steiner’s patented Quick Release HT Mount for rock-solid zero retention shot after shot.

Features

Tri-Beam Laser & Defocused IR Illuminator:
Combines a daylight-visible green aiming laser, an eye-safe Class 1 IR pointer, and an adjustable defocused IR illuminator (95 to 195 mRad) to provide crisp target illumination and acquisition across both CQB and mid-range distances.

Cold-Weather Direct-Diode Green Laser:
Powered by a 520nm direct green diode engineered to perform reliably in sub-zero temperatures as low as -20°C, eliminating the cold-weather dimming common to traditional green lasers.

Dual Remote Ports with Visible Override:
Features dual remote cable ports and an included pressure pad switch supporting standard remote activation alongside instant Visible Override for immediate daylight laser deployment.

Multi-Mode Activation & Power Controls:
Offers high and low power modes, an activation/low-battery indicator LED, and an integrated push-button switch—tap and release for momentary activation or double-tap for 5-minute continuous operation.

Low-Profile Windage & Elevation Adjusters:
Snag-resistant, low-profile turrets allow precise zero adjustments while protecting optical alignment during dynamic movement and heavy recoil.

MIL-SPEC 6061-T6 Aircraft Aluminum Construction:
Machined from high-strength 6061-T6 aircraft aluminum with a non-reflective Type III hardcoat anodized black finish, delivering submersible waterproof durability in extreme weather.

Patented Quick Release (QD) HT Mount:
Self-adjusting QD HT mount locks securely onto any standard Picatinny rail for rapid tool-free attachment and dependable return to zero.

Specifications

Manufacturer Steiner Optics
Model & Item Number DBAL-A3 Civilian / Commercial (Item #9008)
Visible Laser Output & Wavelength Green Laser, Class 3R (<5 mW) / 520nm (±3%)
IR Pointer Output & Wavelength Infrared Laser, Class 1 Eye-Safe (<0.7 mW) / 850nm (±3%)
IR Illuminator Output & Wavelength Adjustable Infrared Illuminator, Class 3R (<4.0 mW) / 830nm (±3%)
Beam Divergence Visible & IR Lasers: 0.5 ±0.3 mRad / IR Illuminator: 95 to 195 mRad
Effective Range / Visibility Visible Green: <100 m / IR Laser & IR Illuminator: <1,500 m
Activation & Remote Controls Integrated Push Button & Dual Remote Cable Ports with Pressure Pad (Includes Visible Override)
Adjustments Low-Profile Windage & Elevation Adjusters
Battery Type & Life (1) CR123A Battery / >3 Hours Runtime
Housing Material & Finish 6061-T6 Aircraft Aluminum / MIL-SPEC Type III Hardcoat Anodized Black
Mount Type Patented Self-Adjusting Quick Release (QD) HT Picatinny Mount
Operating Temperature -20°C to +65°C
Waterproof Rating Submersible (10 m for 2 Hours / Up to 20 m Rated)
Dimensions 3.7 x 2.7 x 1.7 in
Weight (with Battery) 8.3 oz (235 g)
Warranty 2-Year Manufacturer Warranty
