InfiRay Outdoor Hybrid Compact 3.5x Thermal Optic - 640x480 LRF 50mm

InfiRay Outdoor Hybrid Compact 3.5x Thermal Optic - 640x480 LRF 50mm

The Hybrid Compact (HCH50R) is the next evolution of the HYBRID series, combining advanced thermal performance with versatile functionality. It features a 50 mm F/0.9 lens and the industry’s first available 10 µm thermal sensor. The 640×480 InfiRay sensor with a ≤15 mK NETD rating delivers exceptional thermal sensitivity and clarity. The Hybrid Compact functions as a weapon sight, thermal clip-on, or handheld monocular. Its 3.5x native magnification and 60 mm eye relief provide a comfortable, immersive view. The “Fast Engine” low-latency architecture (15 ms) and 60 Hz refresh rate ensure a smooth, life-like image, improving target tracking and accuracy. A 1440×1080 AMOLED display provides a crisp image, while the integrated laser rangefinder and ballistic calculator adjust for drop based on target distance. Built-in photo and
video recording with 64GB of internal storage lets you capture every detail.

Like other HYBRID series models, the HCH50R can be used as a clip-on thermal (with day scope magnification up to 10×) or as a dedicated thermal weapon sight. The industry’s first available 10 µm sensor increases pixel density by 44%, providing high resolution while reducing the overall size of the unit. Powered by a 18650 cell rechargeable battery , the HCH50R includes a Bluetooth remote for seamless clip-on control and a secure DLOC Picatinny rail mount for quick, repeatable attachment. The HCH50R comes with a durable hard case for reliable protection in the field.

Advanced 10μm Thermal Sensor
Industry-first pixel density boost for sharper imaging and reduced unit size.

Versatile Functionality
Operates as a weapon sight, clip-on thermal, or handheld monocular.

High-Performance Optics
50mm F/0.9 Germanium lens with 3.5× native magnification and 8× digital zoom.

Fast Engine Architecture
15 ms latency and 60 Hz refresh rate for smooth, real-time visuals.

AMOLED Display
1440×1080 resolution delivers crisp, vibrant thermal imagery.

Integrated Laser Rangefinder
1200-yard LRF with ballistic calculator for precision targeting.

Robust Build
Magnesium alloy housing with IP67 rating and recoil resistance up to 300 Win Mag.

Multiple Color Palettes
Includes White Hot, Black Hot, Red Hot, Color, Violet, Crimson, and Viridian.

Sensor Specifications

• Resolution: 640×480
• Pixel Size: 10 μm
• Frame Rate: 60 Hz / 30 Hz
• Sensor Sensitivity: ≤15 mK
• Image Processing: InfiRay Fast Engine Low-latency Processor
• Core: InfiRay 640

Optical Specifications

• Objective Lens: 50 mm f/0.9
• Native Magnification: 3.5×
• Digital Zoom: 8×
• Field of View: 7.3° × 5.5°
• Detection Range: 3,060 yards
• Display Type: 0.71-inch AMOLED
• Display Resolution: 1440×1080
• Color Palettes: White Hot, Black Hot, Red Hot, Color, Crimson, Viridian, Violet
• Picture-in-Picture: Yes
• Rangefinder: Integrated 1,200 yd LRF
• Eye Relief: 60 mm
• Diopter Range: -5 to +2

Electronics

• Onboard Recording: Video and Image
• Onboard Storage: 64 GB
• Wireless Connectivity: Image and Video via App
• Data/Power Connector: USB-C
• Power Supply: 18650 Rechargeable (Two Nitecore USB-C cells included)
• Max Operating Time: 7+ Hours Each
• Start-Up Time: <3 Seconds, Instant from Standby

Physical Dimensions

• Size: 9.87″ × 4.05″ × 3.07″
• Weight: 25.56 oz

Enivromental & Warranty

• Warranty: 5 Years
• Housing Material: Magnesium Alloy
• Housing Color: Cerakote® Tan H-235
• Mount Type: DLOC Precision Picatinny Rail Mount
• Ingress Protection: IP67
• Operating Temperature: -25°F – 122°F
• Max Recoil Rating: 1,200 G/s²
